EN 10216-1, P265TR2, Seamless steel tubes for pressure purposes Part 1: Non-alloy steel tubes with specified room temperature properties, Carbon steel pipe, structural steel pipe

EN 10216-1 Seamless steel tubes for pressure purposes Part 1: Non-alloy steel tubes with specified room temperature properties

Standard: EN 10216-1
Equivalent Standard: DIN 1629

Material: P235TR2, 1.0259
Equivalent Materials: St44, St45.8, 1020, 410, SA53 Grade B, S 430, TU E 235 A

Chemistry Composition

C, %

Si, %

Mn, %

P, %

S, %

Cr, %

Ni, %

Cu, %

Mo, %

Nb, %

Ti, %

V, %

Al, %

0.20 max

0.40 max

1.40 max

0.025 max

0.020 max

0.30 max

0.08 max

0.01 max

0.04 max

0.02 max

0.02 min

Mechanical Properties

Tensile Strength , MPa	Yield Strength, MPa	Elongation, %
410-570	265 min	21 min

Outside Diameter & Tolerance

Outside Diameter, mm	Tolerance
OD≤219.1	±1%, 0.5mm min
OD>219.1	±1%, 0.5mm min

Wall thickness & Tolerance

Outside Diameter, mm	WT/OD	Tolerance
OD≤219	WT/OD≤2.5%	±12.5% or ±0.4mm
	2.5%＜WT/OD≤5%
	5%＜WT/OD≤10%
	WT>10%
OD>219.1	WT/OD≤2.5%	±20%
	2.5%＜WT/OD≤5%	±15%
	5%＜WT/OD≤10%	±12.5%
	WT/OD>10%	±10%

EN 10216 part 1 specifies the technical delivery condition for two qualities TR1 and TR2 of seamless tubes of circular cross section with specified room temperature properties made of non-alloy quality steel.

Manufacture: tubes to EN 10216-1 shall be manufactured by hot formed or cold finished.
Heat Treatment: the tubes shall be supplied in normalized or normalising-formed delivery condition.
Inspection & Test: tensile test, NDT, surface inspection and dimension check.
Optional Test: impact test for TR2.

Length: 5800mm; 6000mm; 10000mm; 11800mm; and so on.
Max length: 18000mm

Keyword: seamless steel pipe, seamless steel tube, EN 10216-1
