ASTM A210/ASME SA210 Standard Specification for Seamless Medium-Carbon Steel Boiler and Superheater Tubes

Standard: ASTM A210, ASME SA210
Equivalent Standard: UNI 5462-64, DIN 17175, EN 10216-2, BS 3602 Part I, NF A 49-213, NBR 5592

Material: SA210A1
Equivalent Materials: C18, CFS 430, 20G, STB410

Chemistry Composition

C, %	Mn, %	Si, %	P, %	S, %
0.27 max	0.93 max	0.10 min	0.035 max	0.035 max

Mechanical Properties

Tensile Strength, MPa	Yield Strength, MPa	Elongation, %	Hardness, HB
415 min	255 min	30 min	143 max

Outside Diameter & Tolerance

Hot rolled	Outside Diameter, mm	Tolerance, mm
	OD≤101.6	+0.4/-0.8
	101.6＜OD≤127	+0.4/-1.2

Cold Drawn	Outside Diameter, mm	Tolerance, mm
	OD＜25.4	±0.10
	25.4≤OD≤38.1	±0.15
	38.1＜OD＜50.8	±0.20
	50.8≤OD＜63.5	±0.25
	63.5≤OD＜76.2	±0.30
	76.2≤OD≤101.6	±0.38
	101.6＜OD≤127	+0.38/-0.64

Wall thickness & Tolerance

Hot rolled	Outside Diameter , mm	Tolerance, %
	OD≤101.6, WT≤2.4	+40/-0
	OD≤101.6, 2.4＜WT≤3.8	+35/-0
	OD≤101.6, 3.8＜WT≤4.6	+33/-0
	OD≤101.6, WT>4.6	+28/-0
	OD>101.6, 2.4＜WT≤3.8	+35/-0
	OD>101.6, 3.8＜WT≤4.6	+33/-0
	OD>101.6, WT>4.6	+28/-0
Cold Drawn	Outside Diameter , mm	Tolerance, %
	OD≤38.1	+20/-0
	OD>38.1	+22/-0

ASTM A210/A210M covers minimum-wall-thickness, seamless medium-carbon steel, boiler tubes and boiler flues, including safe ends, arch and stay tubes, and superheater tubes. The tubing sizes and thicknesses usually furnished to this specification are 1⁄2 in. to 5 in. [12.7 to 127 mm] in outside diameter and 0.035 to 0.500 in. [0.9 to 12.7 mm], inclusive, in minimum wall thickness. Tubing having other dimensions may be furnished, provided such tubes comply with all other requirements of ASTM A210/A210M.

Manufacture: the tubes shall be made by the seamless process and shall be either hot-finished or cold-finished, as specified.
Heat Treatment: hot-finished tubes need not be heat treated. Cold finished tubes shall be given a subcritical anneal, a full anneal, or a normalizing heat treatment after the final cold finishing process.
Surface Condition: if pickling or shot blasting or both are required, this shall be specifically stated in the order.
Inspection & Test: chemistry composition analysis, tensile test, flattening test, flaring test, hardness test, NDT, surface inspection and dimension check.

Length: 5800mm; 6000mm; 6096mm; 7315mm; 11800mm; and so on.
Max length: 25000mm, also U bending can be offered.
