GOST 8734-75 Seamless cold-formed steel pipes

Standard: GOST 8734-75
Equivalent Standards: DIN 1629, EN 10216-1

Material: 15ChM
Equivalent Materials: 15CrMo

Chemistry Composition

C, %	Si, %	Mn, %	P, %	S, %	Cr, %	Ni, %	Cu, %	Mo, %
0.11-0.18	0.17-0.37	0.40-0.70	0.025 max	0.025 max	0.80-1.10	0.30 max	0.30 max	0.40-0.55

Mechanical Properties

Tensile Strength , MPa	Yield Strength, MPa	Elongation, %
431 min	226 min	21 min

Outside Diameter & Tolerance

Outside Diameter, mm	Tolerance, mm
5≤OD≤10	±0.15
10＜OD≤30	±0.30
30＜OD≤50	±0.40
OD>50	±0.8%

Wall thickness & Tolerance

Wall Thickness , mm	Tolerance, %
WT≤1	±0.12mm
1＜WT≤5	±10
WT>5	±8
1＜WT≤2.5, OD>110	±12.5

Length: 4000mm; 8030mm; 8050mm; 12010mm; 12030mm; 12050mm; and so on.
Max developed length: 30 meters, also U bending, finning, studded process can be provided.
Option: shot blasting on the outside surface to remove mill scale, make the surface matte colour; surface polishing as preparation work done for further processing, for instance finning.
